特點和優點
· 導熱系數：1.0W
· 熱阻抗：1.47℃-in2/W(@30psi)
· 墊片材料厚度：0.508mm/3.175mm
· 阻燃等級：V-O
· 連續使用溫度：-60℃+180℃
· 絕緣擊穿電壓：﹥10000V
· 設計用于高耐壓性的應用
· 強大的聚酰胺載體提供了優良的電壓擊穿，穿刺和撕裂
· 處理和返工應用自如
GapPad 1000HD間隙墊設計應用于高耐壓性場合。
材料的一個側面上涂覆聚酰亞胺載體易于返工，優異的耐磨特性和耐穿刺處理。
· 典型的應用包括
· 高耐久性應用
· 汽車儲能：超級電容器，電池，功率傳輸，功率逆變器
· 工業汽車應用，如卡車、公共汽車和火車
· 計算機及外圍設備
· 電信
· 與任何熱發電裝置和散熱器
| Property | Imperial Value | Metric Value | Test Method |
| Color | Gray/Black | Gray/Black | Visual |
| Reinforcement Carrier | Polyimide | Polyimide | *** |
| Thickness (inch) / (mm) | 0.020 to 0.125 | 0.508 to 3.175 | ASTM D374 |
| Inherent Surface Tack (1- or 2-sided) | 1 | 1 | *** |
| Density (g/cc) | 2.1 | 2.1 | ASTM D792 |
| Heat Capacity (J/g-K) | 1.0 | 1.0 | ASTM E1269 |
| Hardness (Bulk Rubber) (Shore 00) (1) | 40 | 40 | ASTM D2240 |
| Young's Modulus (psi) / (kPa) (2) | 60 | 414 | ASTM D575 |
| Continuous Use Temp. (°C) | -76 to 358 | -60 to 180 | *** |
| Electrical |
| Dielectric Breakdown Voltage (Vac) | >10,000 | >10,000 | ASTM D149 |
| Dielectric Constant (1000 Hz) | 5.5 | 5.5 | ASTM D150 |
| Volume Resistivity (Ohm-meter) | 1011 | 1011 | ASTM D257 |
| Flame Rating | V-O | V-O | U.L. 94 |
| Thermal |
| Thermal Conductivity (W/m-K) | 1.0 | 1.0 | ASTM D5470 |
| Thermal Performance vs. Strain |
|
|
| Deflection (% strain) | 10 | 20 | 30 |
|
|
| Thermal Impedance (°C-in2/W) 0.040" (3) | 1.70 | 1.59 | 1.47 |
|
|
|
|
|
|
|
|
1) Thirty second delay value Shore 00 hardness scale.
2) Young's Modulus, calculated using 0.01 in/min. step rate of strain with a sample size of 0.79 inch2.
3) The ASTM D5470 test fixture was utilized. The recorded values includes interfacial thermal resistance. These values are provided for reference only. Actual application performance is directly related to the surface roughness, flatness and pressure applied.
|
